Insulated panels
PLYWOOD / POLY floor panel
PUR core. POLY is a facing name, not the foam. Width and length are from the source table. No fire rating or load figure is stated here.
Description
PUR core. POLY is a facing name, not the foam. Width and length are from the source table. No fire rating or load figure is stated here.
Specifications
| Inner face | PLYWOOD |
|---|---|
| Outer face | POLY |
| Use | Floor panel |
| Width | 1110 mm |
| Length | 1 m–13.5 m |
| Core | CFC-free PUR foam, 42 kg/m³ |
| Material | The illustration calls out 8–10 mm plywood, a PUR core, and 0.5 mm galvanized sheet painted RAL 9002. |
| Thickness | 60 / 80 / 100 / 120 / 150 / 200 mm |
Thickness
| 60 mm | No lock |
|---|---|
| 80 mm | With lock |
| 100 mm | With lock |
| 120 mm | With lock |
| 150 mm | With lock |
| 200 mm | With lock |
Catalog tables
Printed source table for this panel family.
